The ADAM Audio S5V is an active vertical 3-way midfield monitor intended for mid-sized and larger control rooms. Despite its relatively compact footprint, the S5V delivers the power and accuracy professional engineers demand of a precision reference-grade monitor; reproducing high-resolution, full-bandwidth audio with stunning clarity. Engineered in Berlin to the strictest tolerances, ADAM's 3rd-generation S series monitors feature cutting-edge technology, including new Extended Linear Excursion (ELE) woofer and DCH midrange driver designs as well as the S-ART tweeter — an updated, even more precise version of ADAM’s acclaimed accelerated ribbon design. With its astounding, ruler-flat 25Hz–50kHz frequency range, ultra-wide and stable stereo imaging, powerful PWM ICE tri-amplification, and ultra-low distortion, the ADAM Audio S5V provides world-class monitoring you can trust, session after session.
Specifications:
- Powered: Yes
- Power Configuration: Tri-amped
- LF Driver Size: 12" woofer
- LF Driver Type: Hexacone
- MF Driver Size: 4" DCH
- MF Driver Type: Carbon Composite
- HF Driver Size: 2" S-ART tweeter
- LF Driver Power Amp: 700W
- MF Driver Power Amp: 300W
- HF Driver Power Amp: 100W
- Total Power: 1100W RMS
- Frequency Response: 25Hz-50kHz
- Crossover Frequency: 250Hz, 3000Hz
- Maximum Peak SPL: ≥128dB
- Input Types: 1 x XLR, 1 x XLR (AES/EBU)
- Output Types: 1 x XLR (AES/EBU)
- USB: 1 x Type B
- Enclosure Type: Ported
- Height: 27.5"
- Width: 15.4"
- Depth: 20.5"
- Weight: 114.5 lbs.
Features:
- Vertical 3-way system with 1 x 12” HexaCone woofer, 1 x 4” DCH midrange, and S-ART tweeter
- S-ART tweeter, handmade in Berlin and manufactured to the tightest tolerances
- Newly designed HPS and MPS waveguides, milled from a solid block of aluminum
- New midrange driver with one-piece hybrid dome/cone (DCH) design
- Custom-built Extended Linear Excursion (ELE) bass drivers
- Custom-designed Symmetrical Magnet Assembly (SMA)
- Spacious bass reflex ports on the front baffle
- Highly efficient 1,100W PWM ICE Power tri-amplification
- Linear frequency response of 25Hz–50kHz
- Maximum peak sound pressure per pair at 1m ≥ 128dB
- Custom DSP engine
- Analog XLR inputs
- AES3 digital I/O
