Yamaha CHR12M 1000-Watt 12" Passive Speaker

If you’re looking for tried and trusted speakers for permanent installation or for quick use around your venue, you can’t go wrong with the CHR Series from Yamaha. At Zoso Music, we’ve found the CHR12M 1000W 12-inch Passive Speaker delivers professional performance at a price that won’t break the bank. The 1.75-inch HF driver and 12-inch LF woofer will submerge your space in high-powered output with minimal distortion that makes for the perfect floor monitor. This 2-way loudspeaker provides clear audio reproduction given its capability for high SPL. Not to mention, you can easily take advantage of dedicated processor settings when you use the CHR12M with Yamaha DSP-equipped amplifiers and other compatible signal processors.

FEATURES

• 2-way passive loudspeaker with 1.75-inch HF and 12-inch LF drivers
• 1000W handling capabilities
• 61Hz–20kHz frequency range with 123dB SPL
• 90° x 90° dispersion
• 57° floor monitor angle
• Compatible with Yamaha PX Series amplifier processor tuning settings (amplifier sold separately)
• Made from durable yet lightweight plywood housing for excellent acoustic performance
• The perfect floor monitor
• 35mm pole socket for use with stands

SPECIFICATIONS

• Powered: No
• Power Configuration: 2-way
• LF Driver Size: 1 x 12" Cone, 1 x 2.5" Voice Coil
• HF Driver Size: 1 x 1.75" Compression Driver
• Impedance: 8 ohms
• Power Rating: 250W Continuous, 500W RMS
• Total Power: 1000W Peak
• Inputs: 2 x speakON
• Frequency Range: 61Hz-20kHz (-10 dB)
• Crossover Frequency: 1.5kHz
• Maximum Peak SPL: 123dB
• Horizontal Coverage Angle: 90 Degrees
• Vertical Coverage Angle: 90 Degrees
• Enclosure Material: Plywood with Black Polyurea Coating
• Mounting Options: Pole, Floor Wedge
• Height: 13.5" (with rubber feet)
• Width: 19.75"
• Depth: 18"
• Weight: 34.3 lbs.
