Warm Audio Wa-47 Large-diaphragm Tube Condenser Microphone

Warm Audio WA-47 Large-diaphragm Tube Condenser Microphone (WA47)

Their acclaimed vintage-inspired compressors, preamps, and mics have famously upset the pro audio price/performance ratio; so when Warm Audio turned its attention to the granddaddy of large-diaphragm tube condenser microphones, you know it had to be good. And it is. With its discrete, transformer-balanced vacuum tube circuitry and custom reproduction capsule, the WA-47 nails the huge, bold sound of the beloved and revered '47 — a sound heard on countless iconic recordings.

Flash back to any top recording studio in the 1960s. You'll see the venerable '47 everywhere. It was Sinatra's vocal mic of choice and one of George Martin's go-to microphones on Beatles sessions, and it now occupies a lofty perch in the pantheon of the greatest microphones ever made. It's this classic circuit design — dating back more than half a century — that Warm Audio closely followed for the WA-47. But this is no mere clone, and innovations abound. Nine available polar patterns and robust 140dB SPL handling translate to incredible versatility; there's literally no source the WA-47 can't finesse with its inimitable seductive sonics. Engineers at Zoso Music who have worked with the iconic original are beyond impressed. And you will be, too.


FEATURES

• Custom reproduction '47-style k47 capsule
• TAB-Funkenwerk (AMI) USA output transformer
• JJ Slovak 5751 vacuum tube
• Wima and Solen French polystyrene capacitors
• Polar patterns: 9 patterns — Cardioid, Omni, figure-of-eight + 6 mixed patterns
• Self-noise: 11dBA
• Dynamic range: 130dBA
• Maximum SPL: 140dB (<0.5% THD)
• Frequency range: 20Hz–20kHz
• Output impedance: 200 ohms
• Rated load impedance: ≥2k ohms
• S/N ratio: 82dBA
• Equivalent noise: 10dBA (IEC651)
• External IEC grounded PSU
• Gotham 5-meter GAC-7, 7-pin tube microphone cable

SPECIFICATIONS

Microphone Type: Tube Condenser
Polar Pattern: Cardioid, Figure-8, Omni (6 additional mixed patterns)
Diaphragm Size: Dual large diaphragm
Max SPL: 140dB SPL <0.5% THD
Output Impedance: 200 ohms
Signal to Noise Ratio: 82dB (A weighted)
Self Noise: 11dB (A weighted)
Tube: JJ Slovak 5751
Power Source: Warm Audio External Power Supply (included)
Color: Nickel
Connector: 7-pin connector with mic cable
