Warm Audio Wa-14 Large-diaphragm Condenser Microphone

Warm Audio WA-14 Large-diaphragm Condenser Microphone (WA14)

Their acclaimed compressors and preamps have famously upset the pro audio price/performance ratio. When Warm Audio turned their attention to microphones, they set high targets: the most iconic large-diaphragm FET condenser mics in history. Behold the WA-14. It's based on a studio classic. Flash back to any top recording facility in the late 1970s. You'll see its venerable progenitor everywhere. On pianos, acoustic guitars, overheads, vocals, brass, percussion — you name it. Zoso Music engineers who have worked with this perennial studio favorite know that the all-brass, edge-terminated CK12 dual-backplate/dual-membrane capsule is a key ingredient in this mic's legendary sound. Warm Audio closely followed this timeless design when they engineered their own LK-12-B-60V Lens Kondensator for the WA-14. Stellar performance, top-shelf parts, and amazing value: that's the Warm formula — and the WA-14 nails it again.


FEATURES

• Large diaphragm condenser microphone with classic circuit topology
• Cardioid, figure-8 and omnidirectional polar patterns
• LK-12-B-60V Lens Kondensator CK12 capsule
• Custom CineMag USA transformer
• all-discrete signal path with tantalum, polystyrene, and WIMA capacitors
• Frequency range: 20Hz-20kHz
• 10dB/20dB switchable output pad
• Impedance: 150 ohms
• Requires 48V phantom power

SPECIFICATIONS

Microphone Type: Condenser
Polar Pattern: Cardioid, Figure-8, Omnidirectional
Diaphragm Size: 1" (25.4mm)
Frequency Range: 20Hz-20kHz
Max SPL: 150 dB SPL
Output Impedance: 150 ohms
Pads: -10dB, -20dB
Color: Black with silver grille
Connector: XLR
Power Source: 48V phantom power
