Live and Preset modes explained
The Walrus Audio EB-10 features two operational modes: Live and Preset. In Live mode, the pedal responds to however you've set the knobs and switches, just like any other pedal. In Preset mode, all controls on the pedal are locked besides the footswitch, which becomes a toggle switch for your three presets (the included manual gives detailed instructions on saving your own custom presets). These two modes make it easy to fine-tune the tone of up to three guitars, save them as presets, and then skip between them during a performance without worrying about your settings being changed.
Walrus Audio EB-10 Preamp/EQ/Boost Pedal Features:
- Versatile tone-sculpting pedal for electric guitar
- 3 rotary knobs to boost/cut low, mid, and high frequencies
- Boost switch engages a 10dB MOSFET boost
- Rugged die-cast enclosure
- Requires 9-volt, 100mA-minimum power supply (sold separately)
Tech Specs
- Pedal Type: Preamp, EQ, Boost
- Compressor/EQ: 3-band EQ
- Analog/Digital: Analog
- Inputs: 1 x 1/4"
- Outputs: 1 x 1/4"
- True Bypass: Yes
- Additional Features: 10dB Boost, 3 x User Presets
- Power Source: 9V DC 100mA Isolated power supply (sold separately)
- Power Usage: 100mA
- Height: 1.54"
- Width: 3.68"
- Depth: 4.67"
- Weight: 0.74 lbs.
- Manufacturer Part Number: 900-1049C
