Jim Dunlop MXR KFK1 Kerry King 10-Band Equalizer

Up to ±12dB of cutting or boosting at 10 different frequencies. Easy to see and adjust onstage with glow-in-the-dark graphics and sliders. 18-volt operation for increased headroom. True bypass switching.

SPECIFICATIONS

• Input Impedance : 470 kΩ
• Output Impedance : 5 kΩ
• Max Input Level ALL Sliders at 0 dB : +14 dBV at 1 kHz
• Max Output Level ALL Sliders at 0 dB : +14 dBV at 1 kHz
• Noise Floor* : -100 dBv
• Filtering ±12db at: 31.25, 62.5, 125, 250,
• 500, 1k, 2k, 4k, 8kHz
• ±12dB shelf at 16kHz
• Bypass : True Hardwire
• Current Draw : 26 mA
