Behringer PRO-1 Tabletop Synthesizer

BEHRINGER PRO-1 TABLETOP SYNTHESIZER

Semi-modular Analog Synthesizer, with Patch Matrix, 64-note Dual Step Sequencer, and Arpeggiator

Behringer PRO-1 Tabletop Synthesizer (PRO1 / PRO 1)

Inspired by one of the most influential monophonic analog synthesizers from the early '80s, the Behringer PRO-1 semi-modular synthesizer packs a huge range of classic synth sounds in a convenient desktop module. Use it on its own without patching anything, integrate it with a Eurorack modular synthesizer environment, or even combine multiple PRO-1 modules to create a monster poly synth — up to 16 voices! However you use it, PRO-1 is sure to impress with its all-analog signal path, vibrant four-pole analog filter, and built-in arpeggiator and step sequencer. Whether you want to conjure the classic bass and lead sounds from the '80s, or simply want to expand your analog synthesis capabilities, there's big value in the Behringer PRO-1 semi-modular analog synthesizer module.

SPECIFICATIONS:

• Type: Desktop Synthesizer
• Analog/Digital: Analog
• Polyphony: Monophonic, 16 Notes via Poly Chain
• Oscillators: 2 x Analog VCO: 3340, 3320 Chips
• Waveforms: Osc A: Sawtooth, Pulse ; Osc B: Sawtooth, Triangle, Pulse
• Noise Generator: White Noise
• Envelope Generator: ADSR (filter), ADSR (amplifier)
• LFO:1 x Analog LFO: Sawtooth, Triangle, Square
• VCA: Yes
• Filter: Lowpass 4-pole 24dB/octave
• Arpeggiator: 3 Patterns: Ascending, Descending, Off
• Sequencer: 64-note, 2 x Sequences
• Analog Inputs: 1 x 1/8" (external audio)
• Analog Outputs: 1 x 1/4", 1 x 1/8"
• Headphones: 1 x 1/8"
• MIDI I/O: In, Out/Thru, USB
• USB: 1 x Type B
• Expansion: Poly Chain multiple Synthesizers
• OS Requirements - Mac: OS X 10.8.5 or later
• OS Requirements - PC: Windows 7 SP1 or later
• Power Supply: 12V DC power supply
• Height: 3.7"
• Width: 16.7"
• Depth: 5.4"
• Weight:4.0 lbs.

FEATURES:

• Analog synthesizer module based on classic dual-VCO synth designs
• Dual oscillators with saw, pulse, and triangle waveforms
• Fat-sounding 24dB filter design can reach self-resonance for expanded sound design potential
• Authentic 3340 and 3320 semiconductors for vintage-accurate sounds
• All-analog signal path with voltage-controlled oscillators, filters, and amplifiers
• Dedicated analog LFO offers simultaneous saw, triangle, and square waveform shapes
• Dual envelope generators for controlling VCF and VCA
• 64-note dual sequencer, and arpeggiator with three different patterns
• Audio input for processing external sounds
