BEHRINGER X32 COMPACT 40-CHANNEL DIGITAL MIXER
40-input, 25-total-bus Digital Mixer with 16 Programmable Mic Preamps, 17 Motorized Faders, Virtual FX Rack, and 7" Color TFT
Behringer X32 COMPACT 40-channel Digital Mixer (X32COMPACT / X-32 / X 32)
Behringer's X32 Compact digital mixer packs everything you need to easily mix and record a live show into a svelte, roadworthy package. But with its amazing-sounding Midas-designed mic preamps, this mixer is also at home in the studio. The X32 Compact's 40 inputs and 16 mix buses give you the flexibility you need, while a USB interface delivers instant compatibility with major DAWs. You also get serious signal processing that can be quickly configured for sessions of any size. Factor in its amazingly intuitive interface and you have a winner: Behringer's X32 Compact is for you. SPECIFICATIONS
SPECIFICATIONS:
- Type: Digital
- Channels: 32
- Inputs - Mic Preamps: 16 x XLR
- Phantom Power: 32 x Channels
- Inputs - Line: 16 x XLR (Mic/Line)
- Inputs - Other: 2 x RCA (Aux), 6 x TRS (Aux)
- Outputs - Main: 8 x XLR
- Outputs - Direct: Assignable
- Outputs - Other: 2 x RCA (Aux), 6 x TRS (Aux)
- Inputs - Digital: 2 x AES50 (32 via Optional Digital Snake)
- Outputs - Digital: 1 x AES/EBU (XLR), 32 x USB, 2 x AES50 (32 via Optional Digital Snake)
- Aux Sends: 16 x Aux Sends
- Send/Return I/O: 6 x TRS
- Busses/Groups: 25 Total (16 x Bus, Main LCR, 6 x Matrix)
- Channel Inserts: Virtual (Physical Assignable to AUX In/Outs)
- Talkback: Yes
- Data I/O: Ethernet, USB, MIDI I/O
- USB: 1 x Type A, 2 x Type B
- Computer Connectivity: USB (32 x 32)
- I/O Expansion Slots: 1 x Slot (Includes 32x32 USB Interface)
- Headphones: 2
- Faders: 17 x 100mm (Motorized)
- EQ Bands: 4-band Parametric (6-band on Mix Bus)
- Effects: Yes
- Transport Controls: via Assign Section
- DAW Control: Yes
FEATURES:
- NEW Auto Mix yields Dugan-style gain sharing
- NEW X-Touch integration allows direct control of parameters over Ethernet
- NEW Set up a full crossover without using a matrix mix
- NEW Reverse polarity on your outputs for easy speaker alignment
- NEW Redesigned X32-Edit app features a new interface, full screen capabilities, floating windows, configurable fader layers, and more
- 40-input, 25-total-bus digital mixer
- 16 mix buses, Main LCR, 6 matrix buses
- 16 programmable Midas-designed mic preamps deliver audiophile sound quality
- Highly configurable, with 40 input channels and 17 motorized faders
- 6 matrix mix buses, 16 mix buses feature inserts, 6-band parametric EQs and dynamics
- Powerful scene management for easy handling of complex productions
- USB interface delivers instant compatibility with major DAWs
- Ultranet connectivity for optional Behringer P-16 Personal Monitoring System
- 48-channel digital snake ready (sold separately) via AES50 ports
- Comes with Tracktion 4 music production software
