Product Features

• 8 award-winning Midas PRO mic preamps and 8 Midas PRO outputs onboard
• 24 motorized 100 mm faders in 3 separate, fully configurable sections
• "Plug and play" remote I/O connectivity for up to 144 input and output signals over 3 AES50 ports featuring Klark Teknik’s SuperMAC technology for ultra-low jitter and latency
• Large main display with capacitive touch screen and adjustable display swivel
• Unique touch-sensitive channel editing section with 11 rotary controls and dedicated color TFT for staying on top of all channel properties
• Optional module for 64x64 channels of audio over Ethernet – supporting WAVES SoundGrid Technology* or Dante/AES67 Technology*
• 48 x 48 channel USB 2.0 audio interface onboard with DAW remote control emulating HUI* and Mackie Control*
• Dual-SD card live recorder/player with up to 64 tracks and markers for identifying song positions
• Additional 4-channel control section with rotary controls, buttons and parameter display for permanent access to mains, matrices or "money-channels"
• Premium FX rack with 8 true-stereo processors and world-class TC algorithms, Lexicon*, Quantec* and EMT* emulations
• Standard FX rack with 8 true-stereo processors for a wide array of modulation, EQ, dynamics etc.
  - also allows blending outboard effects to the mix
• 5 variable plug-in processing slots for all 40 stereo input channels, featuring the most iconic vintage analog equalizers and compressors, plus insert FX slot and 4-band parametric EQ for all 8 stereo aux channels
• Custom Controls offering 16 latching or momentary buttons and 4 rotary controls, easily being configured for preferred functions
• 4 main, 8 matrix and 16 aux stereo buses, featuring dual inserts, 8-band parametric EQ's, stereo imager and full dynamics processing
• 2 Ethernet ports with integrated switch for networked remote control
• Built-in expansion port for optional audio interface cards or digital networking bridges, MADI* and ADAT/WC
• StageCONNECT 32-channel low-latency interface for personal monitoring or analog I/O boxes, AES/EBU stereo digital in
  - and outputs on balanced XLR, 8x8 balanced TRS auxiliary line in
  - and outputs, 2 TRS phones connectors, MIDI I/O and 4 GPIO ports
• Designed and engineered in Germany

Specifications

Input/Output

• 48 Stereo Channels / 96 Inputs
• 144 input and output channels on 3 AES50 ports (48x48 SuperMAC)
• 8 Midas PRO preamp inputs onboard
• 8 Midas PRO output onboard
• 8 balanced TRS AUX inputs
• 8 balanced TRS AUX outputs
• Optional module for 64x64 channels audio over Ethernet
• supports Waves Soundgrid and Dante/AES67
• 48x48 USB 2.0 audio interface onboard with DAW remote control (HUI & Mackie control)
• Dual SD card live recorder/player, up to 64 tracks with markers
• 4 main buses
• 8 matrices
• 16 stereo buses
• StageCONNECT interface (32 channels)
• AES/EBU stereo in and out on balanced XLR
• 2 TRS phone connectors
• MIDI I/O
• 4 GPIO ports

Control Surface

• 24 100mm motorized faders in 3 separate, fully configurable sections
• Custom control section with 16 buttons and 4 rotary controls
• Plug and play remote I/O
• Captive touch screen main display with built
• in swivel
• Touch sensitive channel editing section with 11 rotary controls and dedicated color TFT
• New 4 channel control section with rotary controls , buttons and parameters display for permanent access to mains, matrices or "money
• channels"
• 2 ethernet ports with integrated switch for remote control
• Expansion port for optional audio interfaces, audio bridges, MADI, ADAT, ...

Processing

• Premium FX rack with 8 stereo processors based on TC , Lexicon, Quantec, and EMT emulations
• Standard FX rack with 8 stereo processors for wide array of modulation, EQ, dynamics, and more
• 5 variable plugin processing slots per channel with vintage EQ and compressors
• Insert FX slot and 4
• band PEQ for each AUX channel
• All output buses have dual inserts, 8
• band PEQ, stereo imager and full dynamics processing
